Honeywell Multitrend GR Paperless Recorder

The Honeywell Multitrend GR Paperless Recorder is a comprehensive data acquisition system for process measurement, data logging and control.  These paperless recorders are intended for panel mounting, with a clear XGA TFT, 12.1″ touchscreen display.  Honeywell Multitrend SX Paperless Recorders accept upto 48 analogue inputs and a selection of pulse and digital inputs along with relay alarms outputs.



Honeywell Multitrend GR Recorder benefits….

– Modular, expandable and field upgradable design
– 4, 6, 8, 12, 16, 24, 32, 40 or 48 input channels
– mV, V, mA, Thermocouple, RTD, ohms & SQRT inputs
– CFR21 part 11 compliance for the pharmaceutical industry
– Sampling rates from 20ms (fast scan) upto 60hrs
– Pulse inputs, digital inputs/outputs and relay contact options
– 12.1″ XGA touchscreen display
– Panel mount design with brackets and optional IP65 front bezel
– 240V or 24V supply options, with 24V transmitter power option



Description

The Honeywell Multitrend GR Paperless Recorder, follows on from the original Honeywell SX Paperless Recorders that are now established as an industry leading data acquisition system.



Without introducing an excessive change in the established X-Series design, the Honeywell Multritrend GR Paperless Recorders incorporate an improved XGA Resolution (1024 x 768 pixels), 12.1″ touchscreen display and increaed 1GB internal solid state flash memory as standard (around 242 million data points).  Additionally this memory is expandable upto 4GB (almost 1 billion datapoints).  Memory is simply cleared and information gathered via front access USB or SD card interface or, with optional Honeywell TrendServer software, as an online solution. Honeywell Multitrend GR Paperless Recorders accept upto 48 analogue inputs and a selection of pulse and digital inputs along with relay alarms outputs.



The unique Honeywell Trendview credit system adopted by both Multitrend GR and Multritrend SX paperless recorders also offers the user an array of advanced functionality.  This includes features such as totalisation, high scan rates, thermocouple health check diagnostics, email alarm relay functions and customised displays. For pharmaceutical applications, Honeywell Multitrend GR and Multritrend SX paperless recorders can be ordered with an extended security option. With this enhanced footprint protection, the Honeywell Multitrend paperless recorder is compliant for validation within a CFR21 part 11 system.  The recorder itself offers itself towards multiple batching processes, and pharmaceutical applications are common place.



Honeywell Multitrend GR Recorder benefits….

  • Modular, expandable and field upgradable design
  • 4, 6, 8, 12, 16, 24, 32, 40 or 48 input channels
  • mV, V, mA, Thermocouple, RTD and ohms input types (with SQRT extraction available)
  • Sample, Average, Min/Max logging methods, with continuous and fuzzy logic logging types
  • Sampling rates from 20ms (fast scan) upto 60hrs
  • Pulse inputs, digital inputs/outputs and relay contact options
  • 12.1″ XGA touchscreen display
  • Panel mount design with brackets and optional IP65 front bezel
  • 240V or 24V supply options, with 24V transmitter power option



Fluidic hold an exclusive channel partner agreement with Honeywell Field Products division.  Our instrumentation engineers are product trained and able to help with instrument selection within the full Honeywell Field Product instrumentation portfolio including the entire GR Series Paperless Recorder family.  Fluidic order directly with the Honeywell factory via an exclusive channel partner web portal and hold stock for some common lines.  Please contact either office for more information (Glasgow 0141 641 5920 or Warrington 01925 572401).



Downloads

Download Honeywell Multitrend GR Paperless Recorder Datasheet

Download Honeywell GR Recorders Overview Brochure

Download Honeywell GR Recorders Manual

Download Honeywell TrendManager Suite Manual

Download Networking Honeywell Paperless Recorders

Download Honeywell Recorder Remote Viewer Function

Download Honeywell Paperless Recorders Credits Options

Download Honeywell TrendViewer Software Suite Download
