Honeywell UDC3200 Controller

The Honeywell UDC 3200 Universal Digital Controller is a high end single loop process controller.  Manufactured to a ¼ DIN size, in IP66 wash-down design, the Honeywell UDC3200 offers a reliable uncertainty of 0.20% and a fast scanning rate of 166ms. The UDC3200 possesses adequate power and cost effectively brings with it several advanced features such as enhanced set point programming, fast scanning and on-board diagnostics.



Honeywell UDC3200 Controller specifications include

– 2x Isolated universal inputs
– Within ±0.20% Uncertainty
– Fast scanning rate (166ms)
– Up to 5 Outputs
– Math Functions
– Ethernet or RS-485 communication
– Infrared PC & Pocket PC configuration
– Watertight IP66 front face protection
– Multilanguage prompts
– ¼ DIN Size
– Easily Field Up-gradeable  Modular Design





Description

The Honeywell UDC 3200 Universal Digital Controller is a high end single loop process controller.  Manufactured to a ¼ DIN size, in IP66 wash-down design, the Honeywell UDC3200 offers a reliable uncertainty of 0.20% and a fast scanning rate of 166ms. The UDC 3200 universal controller can be configured with a pocket PC or computer and is very easy to operate and maintain. Its universal spare parts further add to the ease of maintenance. The UDC3200 universal digital controller possesses adequate power and cost effectively brings with it several advanced features such as enhanced set point programming, fast scanning and on-board diagnostics.



Honeywell UDC3200 Controller specifications include

  • 2x Isolated universal inputs i.e. Volt (or mA with included resistor) / RTD / Thermocouple
  • Within ±0.20% Uncertainty
  • Fast scanning rate (166ms)
  • Up to 5 Outputs as follows
    • Current Outputs (4-20mA or 0-20 mA)
    • Electromechanical Relays (5 amps)
    • Solid State Relays (1 amp)
    • Dual Electromechanical Relays (2amps)
    • Open Collector Outputs
  • Math Functions
  • Ethernet or RS-485 communication
  • Infrared PC & Pocket PC configuration
  • Watertight IP66 front face protection
  • Multilanguage prompts
  • ¼ DIN Size
  • Easily Field Up-gradeable  Modular Design



Fluidic hold an exclusive channel partner agreement with Honeywell Field Products division.  Our instrumentation engineers are product trained and able to help with instrument selection within the full Honeywell Field Product instrumentation portfolio including the entire Universal Digital Controller family, which incorporates not only the UDC3200 but the more economically spec’d UDC1200, UDC1700, UDC2500 and flagship UDC3500 model.  Fluidic order directly with the Honeywell factory via an exclusive channel partner web portal and hold stock for some common lines.  Please contact either office for more information (Glasgow 0141 641 5920 or Warrington 01925 572401).

Downloads

Download Honeywell UDC3200 Datasheet

Download Honeywell UDC3200 Manual

Download Honeywell UDC3200 CE Declaration of Conformity

Download Honeywell Controllers Brochure

Download Accutune Solution Note
