Honeywell XYR6000 ISA100 Temperature Transmitter

Part of the Honeywell ISA100 OneWireless™ Network, the XYR6000 temperature transmitter was built on the successful ST 3000 series transmitter line. Options are available with direct mounted temperature sensors, however the standard STTW401 allows a total of 3 inputs from the following combinations:



Honeywell ISA100 XYR6000, STTW401

< 3 thermocouple inputs
< 2 RTD inputs (PT100 etc)
< 3 discrete inputs



The Honeywell OneWireless™ ISA100 network is composed of the Wireless Device Manager (WDM), Field Device Access Point (FDAP) and Honeywell OneWireless XYR6000 series transmitters.  Each XYR6000 transmitter is battery powered by two long-life “D” size lithium batteries. These batteries have an expected lifetime of up to ten years. Transmitter range with the integral antenna is 1,000 ft. (305 m) line of site (LOS) under ideal conditions.



Description

The Honeywell OneWireless™ Network is an industrial wireless mesh network capable of simultaneously supporting ISA100 Wireless field instruments  and, where beneficial, Wi-Fi devices and Ethernet/IP-based devices.  The Honeywell OneWireless™ ISA100 wireless network for wireless field product communications is composed of the Wireless Device Manager (WDM), Field Device Access Point (FDAP) and Honeywell OneWireless XYR6000 series transmitters.



The XYR 6000 temperature transmitter was built on the successful ST 3000 series transmitter line. Several models, with or without direct mounted transmitters can be supplied.  Fluidic are also able to offer the assembly along with thermowells and a variety of RTDs/Thermocouple options as required.



The standard Honeywell XYR6000 temperature ISA100 transmitter, STTW401 with a combination of 3 of…

< 3 thermocouple inputs
< 2 RTD inputs (PT100 etc)
< 3 discrete inputs



The XYR 6000 Wireless Temperature transmitters are part of a broad series of transmitters under the Honeywell XYR6000 line of wireless instrumentation. Using XYR6000 wireless transmitters, customers can obtain data to create information from remote and hazardous measurement locations without the need to run wires, where running wire can be cost prohibitive and/or difficult if the measurement is in a hazardous location. Without wires, transmitters can be installed and operational in minutes, quickly providing information back to your system.  The XYR6000 temperature transmitter is part of the Honeywell OneWireless system and is ISA100.11a compliant.  Each XYR6000 transmitter is battery powered by two long-life “D” size lithium batteries. These batteries have an expected lifetime of up to ten years. Transmitter range with the integral antenna is 1,000 ft. (305 m) line of site (LOS) under ideal conditions.





Downloads

Download Honeywell ISA100 XYR6000 Temperature Transmitters datasheet

Download Honeywell ISA100 XYR6000 Transmitters manual (R220)

Download Honeywell ISA100 OneWireless Overview

Download Honeywell ISA100 OneWireless R220 Release Notes
