Honeywell XYR 6000 ISA100 Wireless Universal I/O

Part of the Honeywell ISA100 OneWireless™ Network, the XYR 6000 Universal input/output transmitter was built on the successful ST 3000 series transmitter line. The two wireless universal I/O models include the STUW700 and STUW701.



Honeywell ISA100 XYR6000, STUW700 (3 input combo)

<3 high level analogue inputs (0-20 mA/4- 20 mA)
<2 thermocouple inputs
<2 discrete inputs



Honeywell ISA100 XYR6000, STUW701 (2 input combo)

<2 high level analogue inputs (0-20 mA/4- 20 mA)
<2 thermocouple inputs
<2 discrete inputs



The Honeywell OneWireless™ ISA100 network is composed of the Wireless Device Manager (WDM), Field Device Access Point (FDAP) and Honeywell OneWireless XYR6000 series transmitters.



Description

The Honeywell OneWireless™ Network is an industrial wireless mesh network capable of simultaneously supporting ISA100 Wireless field instruments  and, where beneficial, Wi-Fi devices and Ethernet/IP-based devices.  The Honeywell OneWireless™ ISA100 wireless network for wireless field product communications is composed of the Wireless Device Manager (WDM), Field Device Access Point (FDAP) and Honeywell OneWireless XYR6000 series transmitters.



The XYR 6000 Universal input/output transmitter was built on the successful ST 3000 series transmitter line. The two wireless universal I/O models include the STUW700 and STUW701.  The STUW700 Universal I/O Transmitter supports a total of three inputs which can be a combination of 1 to 3 high level analog inputs (0-20 mA/4- 20 mA) or 1 to 2 thermocouple inputs or 1 to 2 discrete inputs.  The STUW701 Universal I/O transmitter supports two inputs, which can be a combination of 1 to 2 high level analog inputs (0-20 mA/4-20 mA) or 1 to 2 thermocouple inputs or 1 to 2 discrete inputs plus one discrete output.



The XYR 6000 Wireless Universal I/O transmitter is a part of a broad series of transmitters under the Honeywell XYR 6000 line of wireless products. Using XYR 6000 wireless transmitters, customers can obtain data to create information from remote and hazardous measurement locations without the need to run wires, where running wire can be cost prohibitive and/or difficult if the measurement is in a hazardous location. Without wires, transmitters can be installed and operational in minutes, quickly providing information back to your system.  The XYR 6000 Universal I/O transmitter is part of the Honeywell OneWireless system and are ISA100.11a compliant.  Each XYR 6000 transmitter is battery powered by two long-life “D” size lithium batteries. These batteries have an expected lifetime of up to ten years. Transmitter range with the integral antenna is 1,000 ft. (305 m) line of site (LOS) under ideal conditions.





Downloads

Download Honeywell ISA100 XYR6000 Universal Input/Output Transmitters datasheet

Download Honeywell ISA100 XYR6000 Transmitters manual (R220)

Download Honeywell ISA100 OneWireless Overview

Download Honeywell ISA100 OneWireless R220 Release Notes
